Product Name:	LED 12V DC G4 Corn-Shaped 1.5W Yellow 21lm Globe
Product Code:	8072

Product Features:

• Input voltage: 12V DC Constant voltage
• Wattage: 1.5W
• Life time: 30,000hrs
• Runs off 12V DC battery or constant voltage LED drivers
• G4 base only
• Must be wired parallel
• Ambient temp: -30 to 40°C
• Max.distance to light source: 30m
• Not suitable for dimming

TYPE: LED Globe
BASE: G4
HEIGHT: 38mm
DIAMETER: 16mm
COLOUR TEMP: YELLOWK
LUMENS: 21lm
WATTAGE: 1.5W
DIMMABLE: No
WARRANTY: 3 year replacement warranty
DATA SHEET: available upon request

Product Name: LED 12V DC G4 Corn-Shaped 1.5W Yellow 21lm Globe
Product Code: 8072
Sales Inquiries: 03 9973 6373
Email Inquiries: service@lightingstyle.com.au

Lighting Style
ABN 97 623 567 868
www.lightingstyle.com.au

This product conforms to AS/NZ electrical standards. Unless marked as DIY, electrical installation must be performed by a licensed electrician. The information in this datasheet has been carefully checked and is believed to be accurate - it is our practice to provide accurate information wherever possible; however, final specifications may vary. Performance data given in this document are provided as a guide for the user in determining suitability and do not constitute a warranty. Actual performance is subject to the Warranty and Limitations of Liability. Lighting Style shall not be responsible for special, indirect, or consequential damages or loss in any way connected with this product. Warranty is subject to the product being properly handled, stored, installed, and maintained.
