Product Name:	LED Controller - Single Channel High Power Data Repeater DALI Compatible
Product Code:	5629

This is a 1 channel high power data repeater which offers the ability to expand the signal strength generated by the master controller for dimming circuits. In situations where the load limit is exceeded or more that the limit set by the Master controller it is able to duplicate the signal without signal loss. This means whether dimming via RF, 0-10V, DALI or DMX you can be assured that the dimming signal will always be stable thus avoiding the appearance of dim light over larger areas. Particularly useful where a single master controller is used to control large areas or multiple zones.

MODEL: Power Data Repeater - 1 Channel
TYPE: Controllers
WARRANTY: 3Y
WARRANTY TYPE: Replacement
HEIGHT: 31MM
WIDTH: 54MM
LENGTH: 150MM
VOLTAGE: 12V-24V

Product Name: LED Controller - Single Channel High Power Data Repeater DALI Compatible
Product Code: 5629
Sales Inquiries: 03 9973 6373
Email Inquiries: service@lightingstyle.com.au

Lighting Style
ABN 97 623 567 868
www.lightingstyle.com.au

This product conforms to AS/NZ electrical standards. Unless marked as DIY, electrical installation must be performed by a licensed electrician. The information in this datasheet has been carefully checked and is believed to be accurate - it is our practice to provide accurate information wherever possible; however, final specifications may vary. Performance data given in this document are provided as a guide for the user in determining suitability and do not constitute a warranty. Actual performance is subject to the Warranty and Limitations of Liability. Lighting Style shall not be responsible for special, indirect, or consequential damages or loss in any way connected with this product. Warranty is subject to the product being properly handled, stored, installed, and maintained.
